PET bottle washing &crushing system, plastic flakes recycling machine

FOB Reference Price:Get Latest Price
US $20,000-80,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
PET Plastic Bottle Recycling
Automatic Grade:
Automatic
Production Capacity:
500-3000KG
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
CRSTA
Model Number:
CR-PET
Voltage:
380V and optional
Power(W):
50-150KW
Dimension(L*W*H):
60000*2000*3500mm
Weight:
6-13 TON
Certification:
CE ISO
Warranty:
one year
After-sales Service Provided:
Engineers available to service machinery overseas
Final PET flake purity:
200PPM
Color:
Designed
Capacity:
300/500/1000kg/h
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Plastic film.
Port
GUANGZHOU OR SHENZHEN PORT
Lead Time :
25 days

1500 kg/h PET Bottle Recycling  Line based on 20 years experience



PRODUCT ABOUT



Key Words: 1500kg/h PET Bottle Recycling Line, 1500 kg/h PET Bottle Washing Line, PET Bottle Crushing & Washing Line



Description

 The Process is used to recycle big capacity and stable quality raw material, especially for PSF manufacturer and recycled POY manufacturer with big capacity.



Process Flowchart

De-baling----- Metal Separation ------ Label Scrapping------ Label Separation------- Bottle Pre-washing--------Automatic/Manual Sorting -----Wet Grinding-------Drying ------Hot Flotation------Friction ------ Continuous Rinsing ------Drying ------ Dust Removal ------Packing



Estimated  Plant Parameters

ItemData
Power Installed200 kw
Required Area 700 M2
Manpower10 *

Those marked with "*” shall be determined by raw material composition,using automatical sorting devices or not ,and labor efficiency.





Production Consumption
ItemAverage Consumption Per Ton Flakes
Electricity120 kwh
steam500 kg
Water 2 T
Washing Detergent10 kg




Quality Criteria of Final Product

Description

Characteristic

Intrinsic Viscosity

0.71 ~ 0.78 dl/g depend on bottles I.V.

Bulk density (min./avg./max.)

400/500/600 kg/m3

Flake Size

-          Fraction ≤ 1 mm

-          Fraction ≥ 12 mm

1 ~ 14 mm

< 1 %

< 5 %

Humidity

≤ 2 %

PE,PP

≤ 20 ppm

Label

≤ 20 ppm

Glues/Hot melts

≤ 20 ppm

Organics

≤ 20 ppm

Metals

≤ 20 ppm

In-organics

≤ 20 ppm

PVC

≤ 100 ppm

Total impurity

≤ 200 ppm
